通過式噴淋清洗機的選型和調試，需要綜合考慮產能、潔凈度和成本三者之間的平衡。

The selection and commissioning of a spray cleaning machine require a comprehensive consideration of the balance between production capacity, cleanliness, and cost.

產能匹配是選型第一要?jiǎng)?wù)。設備的非常大處理能力由輸送速度和清洗腔長度共同決定。輸送速度越快，單位時間處理的工件越多。但速度過快可能導致清洗時間不足，影響潔凈度。一般建議的輸送速度為1.5-10米/分鐘。選型時應根據目標產能反推所需速度，并預留20%-30%的余量。

Capacity matching is the top priority in selection. The maximum processing capacity of the equipment is determined by both the conveying speed and the length of the cleaning chamber. The faster the conveying speed, the more workpieces can be processed per unit time. However, excessive speed may result in insufficient cleaning time and affect cleanliness. The generally recommended conveying speed is 1.5-10 meters per minute. When selecting, the required speed should be calculated based on the target production capacity, and a margin of 20% -30% should be reserved.

清洗壓力選擇需因“件”而異。通過式噴淋清洗機的清洗壓力通常在0.5-1.5MPa范圍內。沖壓件、鑄件等表面粗糙的工件可承受較高壓力。精密加工件、表面光潔度要求高的工件則需要較低壓力。需要注意的是，通過式設備的壓力一旦設定，在運行過程中難以調整。因此選型時建議明確工件的壓力耐受范圍。

The selection of cleaning pressure varies depending on the "item". The cleaning pressure of the through spray cleaning machine is usually in the range of 0.5-1.5 MPa. Stamped parts, castings, and other workpieces with rough surfaces can withstand high pressure. Precision machined parts and workpieces with high surface finish requirements require lower pressure. It should be noted that once the pressure of the pass through device is set, it is difficult to adjust during operation. Therefore, when selecting, it is necessary to clarify the pressure tolerance range of the workpiece.

噴嘴布局決定清洗均勻性。通過式噴淋清洗機的噴嘴通常布置在輸送帶的上方、下方和兩側。形成“全周覆蓋”的噴射格局。上方的噴嘴清洗工件頂面；下方的噴嘴清洗底面；兩側的噴嘴清洗側面。對于形狀復雜的工件，還需要增加可調角度的噴嘴。噴嘴間距一般控制在150-300mm，確保噴射覆蓋范圍有重疊，不留死角。

The nozzle layout determines the uniformity of cleaning. The nozzles of the through type spray cleaning machine are usually arranged above, below, and on both sides of the conveyor belt. Form a spray pattern of "full week coverage". The nozzle above cleans the top surface of the workpiece; Clean the bottom surface of the nozzle below; Clean the sides of the nozzles on both sides. For workpieces with complex shapes, it is necessary to add nozzles with adjustable angles. The nozzle spacing is generally controlled between 150-300mm to ensure overlapping coverage and no dead corners.

調試階段的關鍵步驟包括：

The key steps in the debugging phase include:

速度標定。實際輸送速度與設定值可能存在偏差。應使用測速儀校準，確保速度精度在±5%以內。

Speed calibration. There may be a deviation between the actual conveying speed and the set value. A speedometer should be used for calibration to ensure speed accuracy within ± 5%.

壓力測試。各噴嘴的實際壓力應均勻一致。壓力差異超過10%時需檢查管路堵塞或泄漏。

Stress testing. The actual pressure of each nozzle should be uniform and consistent. When the pressure difference exceeds 10%, check for pipeline blockage or leakage.

溫度驗證。清洗液和干燥風的溫度應達到設定值并保持穩定。溫度波動超過±5℃時需檢查加熱系統和溫控傳感器。

Temperature verification. The temperature of the cleaning solution and drying air should reach the set value and remain stable. When the temperature fluctuation exceeds ± 5 ℃, the heating system and temperature control sensor need to be checked.

潔凈度驗證。調試完成后應用標準試件進行清洗測試。通過表面殘留物檢測（如稱重法、顆粒計數法等）驗證清洗效果是否達標。

Cleanliness verification. After debugging, use standard test specimens for cleaning and testing. Verify whether the cleaning effect meets the standard through surface residue detection (such as weighing method, particle counting method, etc.).

日常維護要點：

Daily maintenance points:

噴嘴清理是非常頻繁的維護工作。噴嘴堵塞會導致清洗盲區。建議每班次檢查一次噴嘴狀態。堵塞的噴嘴可用壓縮空氣反向吹掃或拆下用專用工具清理。

Nozzle cleaning is the most frequent maintenance task. Nozzle blockage can cause cleaning blind spots. Suggest checking the nozzle status once per shift. Blocked nozzles can be blown back with compressed air or removed and cleaned with specialized tools.

過濾系統維護直接影響清洗液質量。袋式過濾器需定期更換濾袋；磁性過濾器需定期清除吸附的鐵屑。過濾系統壓差超過設定值時建議立即處理。

The maintenance of the filtration system directly affects the quality of the cleaning solution. Bag filters require regular replacement of filter bags; Magnetic filters need to regularly remove adsorbed iron filings. When the pressure difference of the filtration system exceeds the set value, it must be dealt with immediately.

網帶清潔不可忽視。輸送網帶長期接觸清洗液和污垢。網帶上的殘留物可能污染工件底面。建議每周停機清洗一次網帶。

The cleaning of the mesh belt cannot be ignored. The conveyor belt comes into long-term contact with cleaning solution and dirt. The residue on the mesh belt may contaminate the bottom surface of the workpiece. It is recommended to shut down and clean the mesh belt once a week.
